Esko Kongsberg V-Cut knife blades(Special purpose heavy-duty flat blades)
Esko Kongsberg V-Cut knife blades(Special purpose heavy-duty flat blades)
|
Blade No |
Image |
Description |
Recommended Materials |
|
|
Esko Kongsberg: G42443978, 42443978, BLD-SF212, BK12 |
 |
cutting depth approx. 7 mm |
Flexo clicheés, processed, for Corrugated |
|
|
Esko Kongsberg: G42448589, 42448589, BLD-TZ511 |
 |
cutting depth approx. 17 mm |
Display carton/ corrugated plastic, fluted core board (Re-board, X-board, D-board, etc.), triple wall corrugated sandwich |
|
|
Esko Kongsberg G42448597, 42448597, BLD-TZ512 |
 |
cutting depth approx. 17 mm |
Display carton/ corrugated plastic, fluted core board (Re-board, X-board, D-board, etc.),triple wall corrugated sandwich |
|
|
Esko Kongsberg G34061218, 34061218, BLD-TZ230 |
 |
cutting depth approx. 30 mm |
fluted core board (Re-board, X-board, D-board, etc.), Honeycomb, triple wall corrugated board, tough paper-based materials |
|
Esko Kongsberg BLD-TZ129 |
 |
Maximum cutting thickness17mm - 43/64" |
Corrugated plastic Foam board soft (PUR) Foamed PVC / PS Foamed PVC / PS V-notch Honeycomb / Fluted core board |
|
Esko KongsbergBLD-TZ192 |
 |
Thickness 0.6mm - .024 |
Corrugated plastic Foam board soft (PUR) Foamed PVC / PS Honeycomb / Fluted core board |
|
|
Esko Kongsberg: 42455279, G42455279, BLD-DF570 Atemag: 59008 / 118802 |
 |
cutting depth approx. 16 mm |
fluted core board (Re-board, X-board, D-board, etc.), Honeycomb, triple wall corrugated board, tough paper-based materials |
|
|
Esko Kongsberg: G42455287, 42455287, BLD-SF245 |
 |
cutting depth approx. 7 mm at 45° |
Display carton |
|
|
Esko Kongsberg: G34094581, 34094581, BLD-SF290 |
 |
cutting depth approx. 16 mm at 45° |
triple wall corrugated board, triple wall corrugated sandwich, display carton/ corrugated plastic, fluted core board |
|
|
Esko Kongsberg BLD-DF561 |
 |
|
